Generating Charts


  1. Make sure the version is right in ToolConstants (eg 30).
    1. Make sure the last number (eg 29.0) is in CLDR_VERSIONS
    2. When updating that, also add a new folder with that number (eg 30) in cldr-aux/charts
  2. Use the right status value:
    1. -DCHART_STATUS=beta (default, uses trunk, calls it β)
    2. -DCHART_STATUS=trunk (uses trunk, no β. Used at the end of the release, but before the final data is in cldr-archive)
    3. -DCHART_STATUS=release (only uses the cldr-archive, no β)
  3. Run GenerateAllCharts. The results for each will be in ...cldr-aux/by_type/names.currency.html and so on.
    1. If there is a failure in the Transform charts, it is often because of a missing dependency.
      • Goto CLDRTransforms.DependencyOrder, and add an item there.
      • Example: addDependency("Latin-Bopomofo", "Latin-NumericPinyin");
  4. Spot-check for sanity.
    1. Start from the main page (eg, and click on each of those links.
    2. On each of the subpages, take the first chart on each page, recursively.
    3. Use the "Index" link to go back up (not the back button), and make sure it goes to the right version of the page.
  5. Check into SVN.
    1. Compensate for SVN's brain-dead handling of the mime-type.
      1. In Eclipse, select the enclosing folder.
      2. Right-click > Team > Set Property
      3. Property Name: svn:mime-type
      4. Enter a text property: text/html
      5. Set Property recursively: ON
      6. OK
      7. Then select each of the .css files, and reset the text property to text/css.
  6. In the printout from ChartDelta, there is a listing of the sizes
    1. Something like the following:
      1. newItems 17.70%
      2. deletedItems 3.26%
      3. changedItems 3.32%
      4. unchanged 75.72%
      5. total 702800
    2. Add those new figures to the release page (except skip "unchanged").

Start/End of Release

  1. At the end of the release
    1. Generate with -DCHART_STATUS=trunk
    2. Change the page to add the new release
    3. Check the redirection links on test-chart-links.
    4. On index.html; open it, and fix the version (eg to 25β => 25)
  2. At the start of the release:
    1. change ToolConstants to bump these values as appropriate.
      1. DEFAULT_CHART_VERSION = "28";
    2. In order for chart generation to work properly, you must have archive versions.
      1. You must have versions that match every ToolConstants.CLDR_VERSIONS in a directory.
      2. Best is to download any missing ones from the public zip files, eg
      3. The directory name must match whatever your "ARCHIVE" environment variable is set to.
        1. For example, if ARCHIVE is set to "/foo", then you would need to have CLDR 24.0 checked out as "/'foo/cldr-24.0" for chart generation to work.
    3. generate as above. This will change the version to (say) "25β" visible on each page.
    4. Spot check for sanity as well, as above.
    5. copy index.html from the last version to the current version; open it, and fix the version (eg to 25β)
    6. checkin to SVN
    7. Check the redirection links on test-chart-links.

Modifying the chart programs

The chart programs have grown over time, and need some cleanup. For example, the supplemental charts duplicate code that is now in SupplementalDataInfo.

ShowLanguages. The messages that they use are in a file util/data/chart_messages.html. The right cell contains the key, which is extracted by lines like:

      PrintWriter pw = new PrintWriter(new FormattedFileWriter(index, "Zone \u2192 Tzid", null));

The key will be zone_tzid, in this case.
